The woven bag printing machine is specially designed to provide beautiful printing on the surface of various packaging bags. Thanks to the stable control system, it can provide stable printing speed and fine printing quality. The whole machine is controlled by a computer, so the printing accuracy has been further improved, and the accuracy of 0.01 mm can be achieved when testing the parallelism and straightness. In addition, key components and control systems are from well-known brands, durable and low failure rate. This machine can help you simplify the tedious printing process and maximize the efficiency of the printing workshop. If you want more detailed information, please feel free to contact us.
Features
This woven bag printing machine is made of high-quality steel by precision processing, aiming to ensure the stability, robustness and durability of the whole machine. The main purpose of the high-performance servo motor is to ensure the stability and safety of the printing process, and it will not cause frequent failures. This machine is also equipped with automatic sprinkler, which is equipped with anti-collision protection device to provide effective protection. As a highly automated machine, when the paper or ink is used up, it will automatically send a reminder to reduce the damage rate of the machine. The most important thing is that it can provide a printing effect with high color reversibility, clear outline and smooth surface, thus making your products more competitive.
Item No. | Model No. | QTY | Unit Price (FOB Ningbo) |
1 | FDR-130Z CI flexo printing machine | 1 | |
Notice: | |||
Optional: | |||
Payment Terms |
1. Sea/Air Freight cost &Insurance: to be effected by the buyer. |
2. Package: standard exporting packages. |
3.Delivery time: 90 working days after receiving the down payment.(to be postponed if meet legal holidays) |
4. Payment: 100%TT: 30% down payment, the balance 70% to be paid before shipment. |
5. Warranty: The machine has 12 months’ warranty since the date of buyer's receipt of the machine. |
6.Overseas Service: -- If on-site installation is needed, the charge of accommodation & food and round air-tickets, salary USD 100 per day for technicians should be paid by the buyer. Normal period of installation is 7 days. |
7.The Sender: Email: mary@feidamachine.cn |
8.Quotation company: Zhejiang Feida Machinery Co., Ltd |
Main Parameter
| Items | describe |
Maximum paper width | 1300mm |
Maximum printing width | 1280mm |
Printing repeat | 500-1200mm |
Maximum unwinding dia | 1500mm |
Maximum rewinding dia | 1500mm |
Unwinding type | Air shaft |
Rewinding type | Surface tension |
Gear format | 3.175mm per tooth |
The speed | 150-200m/min |
The thickness of plate | 1.7mm |
The thickness of tape | 0.38mm |
Suitable materials | Paper cup, paper box etc |
The color of machine | Grey and white |
Operation language | Chinese |
Air comsuption | 6KG, 0.6L/Min clear，dry，no water/oil AIR |
Voltage required | 380 VAC +/-10% 3PH 50HZ |
4 tips for printing on woven bags
While printers can make many small changes to their operations to get the best print results on woven bags, there are four basic steps that can improve your prints.
1.Use water-based ink
2.Consider an automatic ink supply system
3.Implement a High Performance Drying System
4.Maintain and maintain your equipment
