Paper Cup Cutting Machine

Description

We can often see many paper cups in shopping malls and restaurants. In order to produce these paper cups, Paper Cup Cutting Machine is indispensable. It can not only cut materials quickly, but also has low use cost, and you don't need to pay high mold fees, so it saves a lot of costs. The edges of the paper cut by this machine are smooth and neat and are exactly the same as the drawings, which can meet the production needs of large, medium, and small manufacturers. In addition, the machine can automatically feed oil. In addition to reducing friction between parts, it can also reduce manual maintenance and make the machine can be used for a longer time.

Features

The Paper Cup Cutting Machine has a very reliable protection system. For example, when the oil pressure is low or a paper jam occurs, the machine will automatically stop running. Filter oil removal and flow switch can make the machine run more stable and convenient for you to monitor whether the oil quantity is sufficient. At the same time, the machine can accurately and stably transport paper in high-speed operation, and can achieve no waste, thus reducing customer costs. The fuselage made of high-quality steel is not easy to deform or rust and has a long service life. If you need special function customization, you can also contact us directly.

Technical Parameter

Electrical configuration

Daily maintenance

In order for Paper Cup Cutting Machine to run well at all times, operators must understand the operation of this Machine. The machine is a combination of different parts, each of which has its own unique features in the production process. Therefore, it is important to fully understand the characteristics of the machine by reading the instruction manual. And the operator also pays attention to daily maintenance, especially the cleaning and lubrication of the machine. They will make the machine more stable and have a longer service life.

Repair

1.Routine inspections are carried out daily to check and lubricate all joints and moving parts above the machine table.

2.Check that the cylindrical pin connecting the parts is loose and the snap ring is in the normal position. If there is any distortion or shift, remove it and replace it with a new spring immediately.

3.Check all fasteners: e.g. nuts, bolts. If loose is found, it should be tightened in time; Failure to do so can cause severe vibration, strumming, or other serious problems.

4.During production, if there are any signs of noise or abnormalities, all operators or service mechanics must pay attention. If this happens, the machine should be stopped immediately and thoroughly inspected.

5.Whenever a problem is identified, only qualified personnel can carry out refurbishment work to ensure the safety of man and machine.

6.The oil pump inlet filter of the lubrication system should be cleaned regularly to avoid clogging of the oil pipe. The new machine should be cleaned once a week for the first two months, and then every two weeks to ensure that the oil is clear.

7.The lubricating oil needs to be changed regularly. The first change of the new machine should be 30 days; After that, the replacement time may be extended to every 6 to 12 months, depending on the condition of the oil.

8.For machines to lubricate parts manually, make sure to oil and clean regularly according to the lubrication schedule.
